2-SAFETYINFORMATION

Handsignals

Whenoperatingthemachine,alwaysworkwithasignalmanwhenyoucarryouttasksthatrequirenecontroland/or

requireyoutoworkinareaswithpoororimpairedvisibility.Makesurethatyouandthesignalmanunderstandthe

signalstobeused.

Starttheengine

PDE0002ATBP11

Shutdowntheengine

PDE0002TBP12

Cometome

Wavehandsbackandforth(palmsinwards).

PDE0003ATBP13

Moveawayfromme

Wavehandsbackandforth(palmsoutwards).

PDE0003TBP14

Gothisfar

PDE0004ATBP15

Allstopandhold

PDE0004TBP16

2-13
