9-ACCESSORIES

Fireextinguisher

Youcaninstallanemergencyreextinguishertothema-

chine.

Twothreadedholesareavailabletotherear-leftupright

oftheupperframetoinstallthereextinguisher(referto

thegurestolocatethethreadedholes).

PleasecontactyourCASECONSTRUCTIONdealerto

obtainthereextinguisher.

SMIL16MEX2313BB1

9-35
