CASE CONSTRUCTION CX17C - Swing Lock Pin

3-CONTROLSANDINSTRUMENTS
Swinglockpin
Onlyforvehiclewithoutinternalswingmo-
torbrake.
WARNING
Misusehazard!
Followtheoperatinginstructionsinthischap-
ter.Anyotherpracticethathasnotreceived
thepriorapprovalofthemanufactureriscon-
sideredtobestrictlyforbidden.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0281A
Theswinglockpinislocatedontheleft-handsideofthe
under-carriage(A)andallowsyoutolocktheupper-struc-
tureinforwarddirectionofthemachine.
Furthermore,itispossibletolocktheupper-structurein
backwarddirectionbyusingtheperforatedplate(B)lo-
catedontheright-handsideoftheupperstructure.
Toensureacorrectupper-structurelocking,alignthehole
oftheperforatedplatewiththeswinglockpin.
NOTICE:itismandatorytolocktheupper-structuredur-
ingthemachineparking,transportationonatrailer,and
handling.
SMIL17MEX0066BB1
Upper-structurelock
Tolocktheupper-structureproceedasfollows:
1.Swingtheupper-structuretoalignaperforatedplate
withtheswinglockpin.
NOTE:itispossibletolocktheupper-structureinboth
directionofmovementsofthemachine.
2.Holdthepin(1)andremovethesplitpin(2)fromthe
upperhole(3).
3.Raisethepin(1)andinsertthesplitpin(2)inthelower
hole(4).
SMIL17MEX0065AA2
Upper-structureunlock
Tounlocktheupper-structureproceedasfollows:
1.Holdthepin(1)andremovethesplitpin(2)fromthe
lowerhole(4).
2.Lowerthepin(1)andinsertthesplitpin(2)intheupper
hole(3).
3-29
