CASE CONSTRUCTION CX17C - Accessories; Bucket Options

9-ACCESSORIES
9-ACCESSORIES###_10_###
Directtbuckets
Thedatashownbelowarereferredtoworkingoperationwiththedozerbladeupandthe185kg(408lb)counter-
weight.
Minimumliftvalueasfunctionofthearmlength:
•
0.96m(37.80in)arm,minimumliftvalue:190kg(419lb).
•
1.12m(44.09in)arm,minimumliftvalue:170kg(375lb).
NOTICE:donotusethemachinewiththeunder-carriageinclosedconguration.Usethiscongurationonlyfor
traveling.Tosettheunder-carriageinextendedconguration,refertopage3-15.
Directtbucketsapplicationasfunctionofthearm
Generalpurposebuckets
Arm
Capacity
ISO7451(Heaped)
WidthMass
0.96m
(37.80in)
1.12m
(44.09in)
0.025m³(0.870ft³)254mm(10.00in)36kg(79.37lb)
●
●
0.028m³(1ft³)305mm(12.01in)39kg(85.98lb)
●
●
0.037m³(1.3ft³)406mm(15.98in)44kg(97.00lb)
●
●
0.042m³(1.5ft³)457mm(17.99in)48kg(105.82lb)
●
●
●Densityofmaterialupto1.6t/m
3
NOTICE:makeparticularattentionwhenswingtheboomtotheleft-handside:theattachmentmaycollidewiththe
canopy.
9-1
