6-MAINTENANCE

Greasepoints(Extensioncylinder)

Greasethebladeevery50h(afterthebreak-inperiod).

Lubricant:CASEAKCELAMOLYGREASE

SMIL16MEX2514FA1

Extensioncylinderpin:twogreasettings

NOTICE:ifyouoperatethemachineinwaterormud,you

mustlubricatetheextensioncylinderconnectionpinsevery

10h.

6-28
