1-GENERALINFORMATION

Productidentication

Yourmachineisahydraulicexcavator.Itconsistsofanundercarriagettedwithtracksandaswingbearingwhich

supportstheupper-structureframe.Theupper-structureframesupportstheattachmentatthefrontendofthema-

chine,plustheengine,hydraulicsandthecanopy.Whentheoperatorworksthecontrols,theengine-drivenpump

delivershydraulicuidtothecontrolvalves.Thecontrolvalvesdistributethehydraulicuidtothevariouscylinders

andhydraulicmotorsemployed.Acoolingsystemmaintainsthehydraulicuidatnormaloperatingtemperature.

SMIL16MEX2247EA1

Whenorderingparts,obtaininginformation,orseekingassistance,alwayssupplyyourCASECONSTRUCTION

DealerwiththetypeandProductIdenticationNumber(PIN)ofyourmachineoraccessories.

Writethefollowinginthespacesbelow:

•

MachineType

•

MachinePIN

•

Machineyearofmanufacture

•

Serialnumbersofhydraulicandmechanicalcomponents

1-5
