3-CONTROLSANDINSTRUMENTS
Left-handsidecontrols
Left-handsidecontrols
SMIL16MEX2327EB1
(1)Safetylocklever(refertopage3-12)
(2)Left-handcontrollever(refertopage3-4)
(3)Armrest
(4)Enginespeedcontrollever(refertopage3-12)
(5)Mainlightswitch.Thisswitchactivatestheheadlight
andtheworklightintwosteps.
Therststepactivatestheheadlightandtheclusterillu-
minationlamp.
Thesecondstepactivatestheworklightandtheindicator
lampontheswitch.
(6)Hydraulicquickcouplingsystemactivationswitch(op-
tional)
Hydraulicquickcouplingsystemswitch(optional)
Thehydraulicquickcouplingsystemswitch(6)isusedto
engageordisengagethehydraulicquickcouplingsystem.
Thisswitchhasaslidingmechanism(A)forpreventing
erroneousswitchoperation.Slideslidingmechanism(A)
inthedirectionofthearrowtolockorunlockthedevice.
Thebuzzersoundswhenthehydraulicquickcouplingsys-
temswitchispressedtodisengagethemovinghook.The
buzzerstopswhentheswitchisreleasedtoengagethe
movinghook.
Toconnectordisconnectanattachment,proceedas
follows:
1.Placetheattachmentinfullcurledpositionfordiscon-
necting.
2.Slidetheswitchmechanism,thenpressandholdthe
hydraulicquickcouplingswitch(6)inreleaseposition.
NOTE:theright-handcontrollevertiltedtoleft-handdi-
rection(bucket-in)activatesthepinsofthequickcou-
pler.
3.Operatethehandcontrolleverinbucket-inpositionin
ordertoactivatethepinsofthequickcoupler.
4.Tilttheright-handcontrollevertotheleft-handdirec-
tionfordisconnectingtheattachment.
5.Releasetheswitch.
SMIL16MEX3181AA2
3-11
