CASE CONSTRUCTION CX17C - Fuse and Relay Locations; Fuses

6-MAINTENANCE
Fuseandrelaylocations
Fuses
Opentheenginedoor(2)toaccesstothefusebox(1)
andpressthehook(3)untilthedooriscompletelyse-
cured.
Thefuseboxcoverindicatesthefunctionandamper-
ageofeachfuse.
NOTICE:beforechangingfusesorrelays,turnthestarter
keytotheOFFposition.
NOTICE:neverreplaceafusewithafuseofadifferent
amperage.
NOTE:usetheprovidedfusepullertoremoveandinstall
thefuses.
SMIL17MEX0864AB1
SMIL17MEX0865FB2
Fusefunctions
(1)B+20A(9)Horn10A
(2)Glowtimer10A(10)SafetysolenoidandEPPR10A
(3)Start5A(11)Fuelfeedandalternator10A
(4)Poweroutlet20A(12)Travelspeed20A
(5)Worklamp20A(13)Spare10A
(6)Quickcoupler20A(14)Spare20A
(7)Monitor25A(15)Spare20A
(8)Travel20A
6-70
