6-MAINTENANCE

Swingbearing

Greasetheswingbearingevery250h.

Lubricant:CASEAKCELA251HEPMULTI-PURPOSEGREASE

Swingbearing:onegreasetting

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointshowningure.

SMIL19MEX0723AA1

SMIL18MEX0755AA2

6-41
