CASE CONSTRUCTION CX17C - Hydraulic Control Lever Operating Pattern

4-OPERATINGINSTRUCTIONS
Hydrauliccontrolleveroperatingpattern
WARNING
Unexpectedmachinemovement!
Pilotcontrolshavetwodifferentmachinecontrolpatterns.Beforeyouoperatethemachine,check
whichpatternisactive.
Failuretocomplycouldresultindeathorseriousinjury.
W1577A
NOTICE:beforestartingthemachine,makesureabout
thepositionoftheleverofthemachinecontrolpattern
valve.
SMIL19MEX0843BA1
Removethetwoscrews(S)andthecover(C)ofthema-
chinecontrolpatternlocatedontheleft-handsideofthe
upper-structure.
SMIL16MEX2334AB2
