CASE CONSTRUCTION CX17C - Parking the Unit; Parking the Machine

4-OPERATINGINSTRUCTIONS
Parkingtheunit
Parkingthemachine
WARNING
Fallhazard!
Jumpingonoroffthemachinecouldcauseaninjury.Alwaysfacethemachine,usethehandrails
andsteps,andgetonoroffslowly.Maintainathree-pointcontacttoavoidfalling:bothhandsonthe
handrailsandonefootonthestep,oronehandonthehandrailandbothfeetonthesteps.
Failuretocomplycouldresultindeathorseriousinjury.
W0141A
•
Alwaysparkthemachineonalevelandrmground.
•
Orienttheupper-structureframeparalleltotheunder-
carriage.Thefrontequipmentshallbepositionedon
thesamesideoftheblade,asindicatedinthepicture.
•
Alignthefrontequipmentparalleltotheupper-structure.
•
Inserttheswinglockpin(ifequipped).Refertopage
3-29.
•
Lowerthebuckettotheground.
•
Lowerthedozerbladetotheground.
SMIL16MEX2307AA1
•
Movebothtravelcontrollevers(1)totheneutralposi-
tion.
•
Setthethrottlelever(2)toLOWIDLING.
SMIL16MEX3238BA2
4-27
