6-MAINTENANCE

Greasepoints(Blade)

Greasethebladeevery50h(afterthebreak-inperiod).

Lubricant:CASEAKCELAMOLYGREASE

SMIL16MEX2514FA1

Dozerbladeconnectionpin:twogreasettings

Dozerbladecylinderpin:twogreasettings

NOTICE:ifyouoperatethemachineinwaterormud,you

mustlubricatethedozerbladeconnectionpinandthe

dozerbladecylinderpinevery10h.

6-27
