6-MAINTENANCE

Boomswingcylinder

Greasetheboomswingcylinderevery250h(afterthebreak-inperiod).

Lubricant:CASEAKCELAMOLYGREASE

Boomswingcylinder:onegreasetting

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointsshowningure.

SMIL19MEX0723AA1

SMIL16MEX2520AA2

6-42
