3-CONTROLSANDINSTRUMENTS
Twopositionswitch
Thetwopositionswitch(5)isusedtoselectthedozer
bladeortrackoperation:
(A)Dozerbladeupordown;
(B)Trackextendorretract.
Refertopage3-15fordetails.
SMIL16MEX2279AA2
Travelalarmswitch(optional)
Thetravelalarmswitch(6),whenpressed,activatesa
buzzertoalarmsurroundingthemachinewhenthema-
chinetravelsforwardandbackward.
SMIL16MEX0391AA3
Starterswitch
Thestarterswitchhasfourpositions:
(1)OFF:engineshut–down
(2)ON:contact,allthesystemsofthemachineoperate.
Thebuzzersoundsfor1s.
NOTICE:ifthisalarmdoesnotsound,theelectriccir-
cuitisabnormal.ContacttheCASECONSTRUCTION
dealerforinspectionandmaintenance.
(3)START :engineignition
(4)HEAT:tobeusedwhentheweathertemperature
isbelow10°C(50°F),untilthepre-heatlamponthe
instrumentclusterturnsOFF(about10s).
NOTE:thestarterkeyisalsousedtolockthesidehoods,
andthestoragecompartment.
SMIL19MEX0842AA4
Emergencystopoftheengineswitch
TheEmergencystopoftheengineswitch(8)isusedto
stoptheengineincaseofemergency.
NOTICE:besuretokeeptheemergencystopoftheen-
gineswitchonthereleasepositionwhenrestarttheen-
gine.
SMIL16MEX2323AA5
3-14
