6-MAINTENANCE

5.Otherwise,ifthemachineisequippedwiththepropor-

tionalswitchontheright-handcontrollever,slideitto

left-handandright-handthreetimesapproximatelyto

releasethepressure.

NOTE:thisproceduredoesnotcompletelyreleasethe

pressure,sowhenoperateonthehydraulicsystem,

loosentheconnectionsslowlyanddonotstandinthe

directionwheretheoildrainsout.

SMIL16MEX1265BA7

6-13
