CASE CONSTRUCTION CX17C - Page 219

9-ACCESSORIES
Theaugerpendulummountassemblyconsistofthe
followingitems:
•
Driveunit(1)
•
Pendulummount(2)
•
Bit(5)
•
Augerbitextension(6):thiscomponent,notshownin
gure,mustbeinstalledbetweendriveunit(1)andthe
bit(5).
SMIL17MEX3033BA37
Theaugercradlemountbracketassemblyconsistofthe
followingitems:
•
Driveunit(1)
•
Cradlemountbracket(3)
•
Pin,bushingandinsertkit(4)
•
Bit(5)
•
Augerbitextension(6):thiscomponent,notshownin
gure,mustbeinstalledbetweendriveunit(1)andthe
bit(5)
•
Adapterplate(7):thiscomponent,notshowningure,
mustbeusedtoengagethecradlemountbracket(3)
withKlaccoupler.
NOTE:theadapterplate(7)isforKlaccouplerapplica-
tionsonly.
SMIL17MEX3034BA38
9-19
