9-ACCESSORIES
Securingthequickcouplingsystem
NOTICE:Thequickcouplingsystemmustbesecuredunlessusinganotherattachment.
Besuretoretractthemobileplateofthequickcouplingsystem.
WARNING
Cuttinghazard!
Thisoperationcouldbedangerous.
Donotputyourhandsnearthemobileplate.
Ifthemobileplateisnotproperlylockedin
theengagedposition,themobileplatecould
suddenlydisengage.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1491A
1.Movetheboom,arm,andbucketcontrolsinorderto
positionthequickcouplingsystem1m(3.3ft)above
theground.
2.Positionthereleasetool(1)onthelockingplateas
showninthegureopposite.
SMIL17MEX0062BB10
3.Pushthereleasetooldowntodisengagethelocking
platefromthestoptab.
SMIL17MEX0063AB11
4.Movethelockingplatetowardthebucketlatchedpo-
sition.Thelockingplateissecuredwhenthesprings
areatrest.
5.Removethereleasetoolandputitinthemachinecom-
partment.
SMIL17MEX0064AB12
9-26
