2-SAFETYINFORMATION
Safetyarea
Thesafetyareaisthespacenecessaryforthemachineto
operateatthemaximumrangeofthetoolandatfullswing
360°plus2m(6.56ft).
(1)Workingarea.
(2)Safetyarea.
SMIL13CEX2517AB1
2-11
