2-SAFETYINFORMATION
(11)Dozerbladeoperation
Location:thissignislocatedontheright-handconsole
box.
Quantity:1
Partnumber:91M9-07391
Thissigndescribesthebladeoperations.
SMIL16MEX0010AA15
(12)Enginecontrolideogram
Location:thissignislocatedontheleft-handconsolebox.
Quantity:1
Partnumber:97MK-07310
Thissignsdescribestheengineoperation.
SMIL19MEX0667AA16
(13)Liftingpoint
Location:thesesignsarelocatedonthedozerblade.
Quantity:2
Partnumber:91MJ-05110
Thissignshowsthelocationwhereaslingisattachedto
handletheexcavatorandthecouplinglocationwhenthe
machinehastobetransportedonatrailer.
SMIL19MEX0713AA17
(14)Greasingpoint
Location:thissignislocatedonthefrontsideoftheupper
structure,closetothegreasingpoints.
Quantity:1
Partnumber:91MJ-04110
Thissignidentiesthegreasingpoints.
SMIL19MEX0723AA18
