3-CONTROLSANDINSTRUMENTS
4.Highspeedtravellight
Thehighspeedtravellight(4)isONwhenthehighspeed
modeisselectedbymeansofthetravelmodeselector
switchlocatedontheright-handtravellever.
SMIL19MEX0854AA5
5.Hydraulicquickcouplerunlockpilotlight
Thehydraulicquickcouplerunlockpilotredlight(5)isON
andthebuzzersoundswhentheactivationswitchofthe
hydraulicquickcouplingsystemisturnedON.
WhentheactivationswitchisturnedOFF,theredlight(5)
turnsOFFandthebuzzerstops.
SMIL19MEX0854AA6
6.Engineoilpressurewarninglight
Theengineoilpressurewarningredlight(6)isONand
thebuzzersoundswhentheoilpressureislow.
Iftheredlight(6)isONduringengineoperation,stopthe
engineimmediately.
SMIL19MEX0854AA7
7.Batterychargingwarninglight
Thebatterychargingwarningredlight(7)isONandthe
buzzersoundswhenthestarterswitchisON.Theredlight
(7)willturnOFFafterstartingtheengine.
Checkthebatterychargingcircuitwhenthislightblinks
duringengineoperation.
SMIL19MEX0854AA8
