Case 445/M2 - Page 16

76212
Figure 2
LUBRICATION SYSTEM LAYOUT (6 cy l. engines)
Routing of oil under pressure
Routing of o il return by gravity
to sump
Introduction of oil
1. Lubrication oil pipe to supercharger − 2. Heat exchanger body − 3. Heat exchanger − 4. Oil rotary expansion pump −
5. Oil fil
t
e
r
E NG I NE S
6
ED. FEBUARY 2003
SECTION 1−GENERAL SPECIFICATIONS
