SECTION 00 -- GENERAL INFORMATION -- CHAPTER 1
00-27
4. Raise the tractor three-point hitch high enough to
install the jack, 1, in the lift frame mount and
install the pin, 2, to secure it.
5. Disconnect the limit chains, 3, from the rear of the
tractor.
6. Lower the cutter bar to the ground in the mowing
position and lower the tractor three-point high so
that the mower frame is sitting on the jack as
shown.
7. Loosen, unlock, or remove the tractor sway bars
or equivalent.
8. Disconnect the three-point hitch arms from the lift
links, 4, and the top link, 5, from the mower.
9. Disconnect the hydraulic hose, transport latch
rope, and the PTO from the tractor.
A5301-02
1
2
4
5
3
44
