SECTION 58 -- ATTACHMENTS AND HEADERS -- CHAPTER 1
58-8
13/16″ (21mm)
19992986
1
17
REASSEMBLY
Clean and inspect all parts. Replace bearings if any
pitting or brinelling of bearing cup or cone is noticed.
Inspect shafts for excessive wear or damage to
splined surfaces, and for damage on bearing shoul-
ders. Check gear teeth for chipping or cracks, and
the mating splined bores for wear. Replace any dam-
aged parts. Thoroughly clean all sealant residue off
the bottom surface of the gearbox housing and the
cover mounting surfaces.
