8. (Phoenix Only) The exhaust system is designed to push fumes through the
exhaust hose (3” ID) at approximately 125 CFM (unducted). The exhaust system
will push fumes through the fl exible exhaust hose at approximately 55 - 75 Kmh
(40 - 55 mph). The exhaust hose should be a maximum length of 16 feet
(maximum 8 feet vertical within 16 feet).
WARNING
To avoid insuffi cient exhaust, never permit the exhaust fl ow rate to
fall below 50 CFM.
Unpacking
1. Carefully open the shipping cartons, using caution to avoid puncturing or
tearing the foam packaging. Remove the foam and cardboard packing material.
NOTE
Retain all packing material for use if returning the instrument to the
manufacturer for service.
2. With at least two people for lifting, locate the handles on each side of the
lifting carton and lift the instrument from the shipping carton and place it on a
laboratory bench. Carefully remove the lifting carton and plastic wrap from
the instrument.
3. Open the instrument door and remove the packing from the four studs in the
bottom of the instrument cavity.
