Calibration

The circuitry of the furnace thermocouple can be calibrated using the software

calibration procedures and the CEM calibration instrument (part number 271060).

Calibration of the thermocouple is required if the instrument software or the thermo-

couple is replaced. If calibration data is lost for other reasons, the previous calibration

parameters can be entered, and calibration will not be required.

CEM Method Menu

EDIT/CREATE QUICK TEST LOAD

METHOD METHOD

Current Method: XXX

Press START to Begin

1. With the CEM Method Menu displayed, press the SETUP key.

Setup Menu

AUTO START/STOP PROGRAM OPTIONS

CALIBRATION PRINTER SETUP

EXTERNAL BALANCE COMPANY NAME

SYSTEM OPTIONS DELETE METHOD

2. Using the arrow keys, highlight Calibration. Press the SELECT key.

Calibration

FURNACE TEMPERATURE CALIBRATION

PREVIOUS CALIBRATION VALUES

Furnace Temperature Calibration

Note: To enter previous calibration values, proceed to step 18.

3. Remove the screw in the thermocouple access door on top of the instrument

cover and remove the access door.

4. Disconnect the thermocouple plug from the thermocouple wiring connector.

5. Install the connector of the CEM calibration instrument into the thermocouple

wiring connector.

6. Using the arrow keys, highlight Furnace Temperature Calibration. Press the

SELECT key.
