CEM Phoenix User Manual

84
Microwave Power Measurement
1. Remove the screw in the thermocouple access door on top of the instrument
cover and remove the access door.
2. Disconnect and remove the furnace thermocouple.
3. Open the instrument door. Remove the furnace from the instrument cavity.
4. Install and connect the furnace thermocouple.
CEM Method Menu
EDIT/CREATE QUICK TEST LOAD
METHOD METHOD
Current Method: XXX
Press START to Begin
5. With the CEM Method Menu displayed, press the SETUP key.
Setup Menu
AUTO START/STOP PROGRAM OPTIONS
CALIBRATION PRINTER SETUP
EXTERNAL BALANCE COMPANY NAME
SYSTEM OPTIONS DELETE METHOD
6. Using the arrow keys, highlight System Options. Press the SELECT key.
System Options
TIMERS SELECT LANGUAGE
TESTS
INFORMATION
7. Using the arrow keys, highlight Tests. Press the SELECT key.
Tests
POWER TEST
8. Press the SELECT key.
