CEM Phoenix User Manual

10
• Blower Assembly – exhausts heat and smoke from instrument cavity during
sample ashing.
• Magnetron Cooling Fan – draws air through the magnetron.
• Fuses – prevent electrical power overload.
• Power Cord Receptacle – receives the female end of the power cord.
• Power Cord – conducts electrical power from the AC outlet to the instrument. It
is detachable.
• On/Off Switch – turns electrical power to the instrument on and off.
• Nameplate – lists instrument model and serial number.
• Voltage Selection Switch – permits unit to operate properly with line voltages
from 208 to 230V (60 Hz) or 220 to 240V (50 Hz).
• Solenoid Connector – connects solenoid to power panel. (AirWave only)
• Filter Dryer – removes water and contaminate. (AirWave only)
• Air Regulator – regulates pressure to the airfl ow amplifi er. (AirWave only)
• Pressure Gauge – permits monitoring of regulated pressure in airfl ow amplifi er.
(AirWave only)
• Airfl ow Amplifi er – exhausts heat and smoke from instrument cavity during
sample ashing (AirWave only)
H
dgi
oud
v,
;f
a
dsv
Bb
g
fd
g
jh
id
jmm kk
o
[p
o m
p
h
u
ih
v
ciu
h
n
i
n
u
h
ja
e
f
8
o
p
aj 9
0
p
fa
d
f.
H
if
co
p
a
ka
[
o
p
ia
fih
b
Nameplate
Power
Cord
On/Off
Switch
Power
Cord
Receptacle
Fuses
Voltage
Selection
Switch
Blower
Assembly
Magnetron
Cooling
Fan
Figure 6. Phoenix (Rear View)
