CHAPTER 2 - SPECIFICATION
The P-Series VFDs can be used in phase conversion (single-phase input power and three-phase output at the
same voltage) applications. The below tables contain VFD ratings for three-phase and phase-conversion
variable torque applications. In order for Cerus to maintain warranty on VFD for phase conversion
applications, the customer should call Cerus with application information and line reactor installation is
required. Refer to page 3-7 for power wiring description.
2.1 200~230V Class 7.5~40HP (5.5~30kW)
Part Number (CI-xxx-P2) & UL Type
(U1-Type 1, UO-Open Type)
007
U1
010
U1
015
U1
020
U1
(6)
025
U1
(6)
030
U1
(6)
040
U1
(6)
Standard Duty Variable Torque
Motor Rating
(1)
HP
(1)
7.5 10 15 20 25 30 40
kW
5.5 7.5 11 15 18.5 22 30
FLA[A]
24 32 46 60 74 88 115
Heavy Duty Variable Torque or
Standard Duty Constant Torque
Motor Rating
(1)
HP
(1)
5 7.5 10 15 20 25 30
kW
3.7 5.5 7.5 11 15 18.5 22
FLA[A]
17 23 33 44 54 68 84
Output ratings
Capacity [kVA]
9.1 12.2 17.5 22.9 28.2 33.5 43.8
Voltage
(2)
3φ 200 ~ 230 VAC
Frequency 0.01 ~ 120 Hz
Input ratings
Voltage
(5)
3φ 200 (-15%) ~ 230 VAC (+10 %)
Frequency 50/60 Hz (± 5 %)
Weight kg
(lbs.)
4.9
(
11
)
6
(
13.2
)
6
(
13.2
)
13
(
29
)
13.5
(
30
)
20
(
44.1
)
20
(
44.1
)
VFD Ratings for Phase Conversion Application
Single-Phase Input Viltage
[V]
1φ 200 ~ 230 VAC
Single-Phase Input Current
24 32 46 60 74 88 115
VFD Output Current
[A] 12 16 24 32
37
46 60
