CERUS CI-007-P2 - Drv] Drive Parameter Group

Chapter 5 – Parameter List
5-5
5.3 [DRV] Drive parameter group
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
DRV-00 9200 Command/ Output Frequency Cmd. freq
0 to FG1-30[Hz]

6-10
DRV-01 9201 Step Frequency 1 Step Freq-1
DRV-02 9202 Step Frequency 2 Step Freq-2
DRV-03 9203 Step Frequency 3 Step Freq-3
DRV-04 9204 Step Frequency 4 Step Freq-4
DRV-05 9205 Step Frequency 5 Step Freq-5
DRV-06 9206 Step Frequency 6 Step Freq-6
DRV-07 9207 Step Frequency 7 Step Freq-7
DRV-08 9208 Step Frequency 8 Step Freq-8
DRV-09 9209 Step Frequency 9 Step Freq-9
DRV-10 920A Step Frequency 10 Step Freq-10
DRV-11 920B Step Frequency 11 Step Freq-11
DRV-12 920C Step Frequency 12 Step Freq-12
DRV-13 920D Step Frequency 13 Step Freq-13
DRV-14 920E Step Frequency 14 Step Freq-14
DRV-15 920F Step Frequency 15 Step Freq-15
DRV-16 9210 Jog Frequency Setting Jog Freq
DRV-17 9211 Output Current Display Current * [A]
Display
DRV-18 9212 Motor Speed Display Speed * [rpm]
DRV-19 9213 DC link Voltage Display DC Link Vtg * [V]
DRV-20 9214 User Parameter Display User Disp *
DRV-21 9215 Current Trip Display Fault *
DRV-22 9216 Target/Output Frequency Display Tar. Out. Freq. * [Hz]
DRV-23 9217 Reference/Feedback Values Display Ref. Fbk. Freq. * [Unit]
DRV-24 9218 Frequency or Speed Selection
0 Hz
Hz or Rpm 
6-11
1 RPM
DRV-25 9219 R/F=%, T/O=Hz for PID R/F/T/O 0-100% and 0-Max.Hz
Display
DRV-26 921A V1, V2, V1S, and I Readings V1, V2, V1S, I Raw Value 0-4000
DRV-27 921B EXT-PID Tar/Out Parameter ExtPID Para 0-100%
DRV-91 925B
Drive Mode 2
(2
nd
Source)
DriveMode2
0 (Keypad)

1 (Remote-1)
2 (Remote-2)
DRV-92 925C
Speed Control Reference 2
(2
nd
Source)
Speed Crl 2
0 (Keypad-1)

1 (Keypad-Up/Dwm)
2 (V1)
3 (V1S)
4 (I)
5 (V+I)
6 (Pulse)
