Chapter 10 – Modbus-RTU Communication
10-3
10.5 Parameter code list
<Common area>: Area accessible regardless of VFD models
Address Parameter Unit Unit R/W Data value
0x0000 VFD model R 9 : P series
0x0001
VFD capacity
R
4: 5.5kW, 5: 7.5kW
6: 11kW, 7: 15kW, 8: 18.5kW
9: 22kW, A: 30kW
B: 37kW,
C: 45kW D: 55kW, E: 75kW
F: 90kW
10: 110kW, 11: 132kW,
12: 160kW, 13: 220kW, 14: 280kW
0x0002
VFD Input Voltage
R
0 : 220V Class
1 : 400V Class
0x0003
S/W Version
R
(Ex) 0x0100 : Version 1.00
0x0101 : Version 1.10
0x0005 Frequency Reference 0.01 Hz
R/W
0x0006 Run Command (Note 1)
R/W
BIT 0: Stop (S)
BIT 1: Forward run (F)
BIT 2: Reverse run (R)
BIT 3: Fault reset (0->1)
BIT 4: Emergency stop
BIT 5: Not used
R
BIT 6, BIT 7: Run/Stop command source
0(Terminal), 1(Keypad), 2(Option) 3: Int. 485
BIT 8 ~12: Freq. reference
0 ~ 16: Multi-step speed freq. (0, 2~16)
17 ~ 19: UpDown (Up, Down, UD Zero)
20 ~ 21: RESERVED
22 ~ 25: Analog (V1, V1S, I, V1I)
26: Pulse 27: Sub 28: Int. 485
29: Option, 30: Jog, 31 : PID
BIT 15: set when Network error
0x0007 Acceleration Time 0.1 sec
R/W
0x0008 Deceleration Time 0.1 sec
R/W
0x0009 Output Current 0.1 A R
0x000A Output Frequency 0.01 Hz R
0x000B Output Voltage 0.1 V R
0x000C DC Link voltage 0.1 V R
0x000D Output power 0.1 kW R
0x000E Operating status of VFD R
BIT 0: Stop
BIT 1: Forward running
BIT 2: Reverse running
BIT 3: Fault (Trip)
BIT 4: Accelerating
BIT 5: Decelerating
BIT 6: speed arrival
BIT 7: DC Braking
BIT 8: Stopping
Bit 9: not Used
BIT10: Brake Open
BIT11: Forward run command
BIT12: Reverse run command
