Chapter 5 – Parameter List
5-21
5.12 [APP] Parameter Group Default Settings
CODE
LCD Keypad
Display
Basic
Supply
Fan
Exhaust
Fan
Cooling
Tower
Circul.
Pump
Subm.
Pump
Vacuum
Pump
Const.
Torq.
APP-00
Jump Code
40 40 40 40 40 40 40 40
APP-01
PID F Gain
0.0 [%]
0.0 [%]
0.0 [%]
0.0 [%]
0.0 [%]
0.0 [%]
0.0 [%]
0.0 [%]
APP-02
Aux Ref Mode
0 (No)
0 (No)
0 (No)
0 (No)
0 (No)
0 (No)
0 (No)
0 (No)
APP-03
Aux Ref Sel
2 (V1) 2 (V1) 2 (V1) 2 (V1) 2 (V1) 2 (V1) 2 (V1) 2 (V1)
APP-04
PIDFB I Max
20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA]
APP-05
PIDFB V1 Max
10
.0
[V]
10
.0
[V]
10
.0
[V]
10
.0
[V]
10
.0
[V]
10
.0
[V]
10
.0
[V]
10
.0
[V]
APP-06
PIDFB P Max
100.0 [kHz] 100.0 [kHz] 100.0 [kHz] 100.0 [kHz] 100.0 [kHz] 100.0 [kHz] 100.0 [kHz] 100.0 [kHz]
APP-09
PID D Time
0.0 [msec] 0.0 [msec] 0.0 [msec] 0.0 [msec] 0.0 [msec] 0.0 [msec] 0.0 [msec] 0.0 [msec]
APP-12
PID OutScale
100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%]
APP-13
PID P2 Gain
100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%]
APP-14
P Gain Scale
100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%]
APP-17
PID U Fbk
0 (No)
0 (N
o)
0 (No)
0 (No)
0 (No)
0 (No)
0 (No)
0 (No)
APP-20
2nd Acc Time
5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec]
APP-21
2nd Dec Time
10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec]
APP-22
2nd BaseFreq
60
.00
[Hz]
60
.00
[Hz]
60
.00
[Hz]
60
.00
[Hz]
60
.00
[Hz]
60
.00
[Hz]
60
.00
[Hz]
60
.00
[Hz]
APP-23
2nd V/F
0 (Linear) 0 (Linear) 0 (Linear) 0 (Linear) 0 (Linear) 0 (Linear) 0 (Linear) 0 (Linear)
APP-24
2nd F Boost
2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%]
APP-25
2nd R Boost
2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%]
APP-26
2nd Stall
100 [%]
100 [%]
100 [%]
100 [%]
100 [%]
100 [%]
100 [%]
100 [%]
APP-27
2nd ETH 1min
130[%] 130[%] 130[%] 130[%] 130[%] 130[%] 130[%] 130[%]
APP-28
2nd ETH Cont
120[%]
120[%]
120[%]
120[%]
120[%]
120[%]
120[%]
120[%]
APP-29
2
nd
R Curr
By VFD HP By VFD HP
By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP
APP-41
Starting Aux
1 1 1 1 1 1 1 1
APP-44
F-in L-out
Yes Yes Yes Yes Yes Yes Yes (No)
APP-45
All Stop
(No)
(No)
(No)
(No)
(No)
(No)
(No)
(No)
APP-62
Regul Bypass
0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No)
APP-66
AutoCh Mode
0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None)
APP-67
AutoEx Intv
72:00
72:00
72:00
72:00
72:00
72:00
72:00
72:00
APP-68
AutoEx Level
20.0 [Hz] 20.0 [Hz] 20.0 [Hz] 20.0 [Hz] 20.0 [Hz] 30.0 [Hz] 20.0 [Hz] 20.0 [Hz]
APP-69
Interlock
0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No)
APP-78
Ext PI Mode
0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No) 0 (No)
APP-79
Ext Ref Sel
3 (KeyPad) 3 (KeyPad) 3 (KeyPad) 3 (KeyPad) 3 (KeyPad) 3 (KeyPad) 3 (KeyPad) 3 (KeyPad)
APP-80
Ext SetPoint
500.0 [CUST] 500.0 [CUST] 500.0 [CUST] 500.0 [CUST] 500.0 [CUST] 500.0 [CUST] 500.0 [CUST] 500.0 [CUST]
APP-81
Ext Fbk Sel
0 (I) 0 (I) 0 (I) 0 (I) 0 (I) 0 (I) 0 (I) 0 (I)
APP-82
ExtFbk Unit
CUST CUST CUST CUST CUST CUST CUST CUST
APP-84
ExtFbk UnitH
1000.0CUST
1000.0CUST 1000.0CUST 1000.0CUST 1000.0CUST 1000.0CUST 1000.0CUST 1000.0CUST
APP-85
ExtPID PGain
1.0 [%] 1.0 [%] 1.0 [%] 1.0 [%] 1.0 [%] 1.0 [%] 1.0 [%] 1.0 [%]
APP-86
ExtPID ITime
10.0 [sec]
10.0 [sec]
10.0 [sec]
10.0 [sec]
10.0 [sec]
10.0 [sec]
10.0 [sec]
10.0 [sec]
APP-87
ExtPID DTime
0 [msec] 0 [msec] 0 [msec] 0 [msec] 0 [msec] 0 [msec] 0 [msec] 0 [msec]
APP-88
ExtPID Lmt H
100.00 [%] 100.00 [%] 100.00 [%] 100.00 [%] 100.00 [%] 100.00 [%] 100.00 [%] 100.00 [%]
APP-89
ExtPID Lmt L
0.00 [%] 0.00 [%] 0.00 [%] 0.00 [%] 0.00 [%] 0.00 [%] 0.00 [%] 0.00 [%]
APP-90
ExtPID Scale
100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%]
APP-91
Ext P2 Gain
100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%]
APP-92
Ext P Scale
100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%] 100.0 [%]
APP-93
ExtPID FGain
0.0 [%] 0.0 [%] 0.0 [%] 0.0 [%] 0.0 [%] 0.0 [%] 0.0 [%] 0.0 [%]
APP-95
ExtPIDOutInv
No No No No No No No No
APP-97
ExtPIDLoopT
100 [msec] 100 [msec] 100 [msec] 100 [msec] 100 [msec] 100 [msec] 100 [msec] 100 [msec]
