CERUS CI-007-P2 - Fg1] Parameter Group Default Settings

Chapter 5 – Parameter List
5-8
FG1-58 933A No Motor Trip Current Level NoMotorLevel 5 to 100 [%]

FG1-59 933B No Motor Trip Time Setting NoMotorTime 0.1 to 10.0 [Sec]
FG1-60 933C Electronic Motor Overload ETH Select
0
(No)

1 (Yes)
FG1-61 933D
Electronic Thermal Level for 1
Minute
ETH 1min FG1-62 to 200 [%]
FG1-62 933E
Electronic Thermal Level for
Continuous
ETH Cont
50 to FG1-61[%]
(Maximum 200%)
FG1-63 933F Motor Cooling Type Selection Motor Type
0
(Self-cool)

6-16
1 (Forced-cool)
FG1-64 9340 Overload Warning Level OL Level 30 to 110 [%]

FG1-65 9341 Overload Warning Time OL Time 0.0 to 30.0 [sec]
FG1-66 9342 Overload Trip Selection OLT Select
0
(No)
1 (Yes)
FG1-67 9343 Overload Trip Level OLT Level 30 to 150 [%]
FG1-68 9344 Overload Trip Delay Time OLT Time 0.0 to 60.0 [sec]
FG1-69 9345
Input/Output Phase Loss
Protection
Trip Select 000 to 111 (Bit Set) 
FG1-70 9346 Stall Prevention Mode Selection Stall Mode
0 (No)

1 (Yes)
FG1-71 9347 Stall Prevention Level Stall Level 30 to 200 [%]

FG1-72 9348 Accel/Decel Change Frequency Acc/Dec Ch F 0.00 to FG1-30 [Hz]
6-17
FG1-73 9349 Reference Range for Accel/Decel Acc/Dec Freq
0 (Max freq)
1 (Delta freq)
FG1-74 934A Accel/Decel Time Scale Time Scale
0
(0.01 sec)

6-17
1 (0.1 sec)
2 (1 sec)
FG1-81 9351
Start Delay time after Run
Command is activated
Run Delay T 0 to 6000 sec 
FG1-90 935A Up/Down Save Mode UpDnSaveMode
0
(No)

1 (Yes)
FG1-91 935B Up/Down Save Freq xx.xxHz 0.00 to FG1-30 [Hz] Display
5.6 [FG1] Parameter Group Default Settings
CODE
LCD Keypad
Display
Basic
Supply
Fan
Exhaust
Fan
Cooling
Tower
Circul.
Pump
Subm.
Pump
Vacuum
Pump
Const.
Torq.
FG1-00 Jump Code
70 70 70 70 70 70 70 70
FG1-02 Acc. Pattern
(Linear) (Linear) (Linear) (Linear) (Linear) (Linear) (Linear) (Linear)
FG1-03 Dec. Pattern
(Linear) (Linear) (Linear) (Linear) (Linear) (Linear) (Linear) (Linear)
FG1-04
Start Curve 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%]
FG1-05
End Curve 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%]
FG1-10 PreHeat Mode
(No) (No) (No) (No) (No) (No) (No) (No)
FG1-11
PreHeatLevel 20 (%) 20 (%) 20 (%) 20 (%) 20 (%) 20 (%) 20 (%) 20 (%)
FG1-12
PreHeatDuty 30 (%) 30 (%) 30 (%) 30 (%) 30 (%) 30 (%) 30 (%) 30 (%)
FG1-20
Start Mode
Accel
Accel Accel Accel Accel Accel Accel Accel
FG1-21
DcSt Time 0.0 [sec] 0.0 [sec] 0.0 [sec] 0.0 [sec] 0.0 [sec] 0.0 [sec] 0.0 [sec] 0.0 [sec]
FG1-22
DcSt Value 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%]
FG1-24
DcBr Delay 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec]
FG1-25
DcBr Freq
20.00 [Hz]
20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz]
FG1-26
DcBr Time
3.0 [sec] 3.0 [sec] 3.0 [sec] 3.0 [sec] 3.0 [sec] 3.0 [sec] 3.0 [sec] 3.0 [sec]
