CERUS CI-007-P2 - Page 52

Chapter 5 – Parameter List
5-9
CODE
LCD Keypad
Display
Basic
Supply
Fan
Exhaust
Fan
Cooling
Tower
Circul.
Pump
Subm.
Pump
Vacuum
Pump
Const.
Torq.
FG1-27
DcBr Value
50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%]
FG1-28
Safety Stop (No) (No) (No) (No) (No) (No) (No) (No)
FG1-29
Line Freq 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz]
FG1-30
Max Freq 60.00 [Hz]
60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz]
FG1-31
Base Freq 60.00 [Hz]
60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz]
FG1-32
Start Freq 0.5 [Hz] 0.5 [Hz] 0.5 [Hz] 0.5 [Hz] 0.5 [Hz] 0.5 [Hz] 0.5 [Hz] 0.5 [Hz]
FG1-40
V/F Pattern (Linear) (Linear) (Linear) (Linear) (Linear) (Linear) (Linear) (Linear)
FG1-41
User Freq 1
15.00 [Hz]
15.00 [Hz] 15.00 [Hz] 15.00 [Hz] 15.00 [Hz] 15.00 [Hz] 15.00 [Hz] 15.00 [Hz]
FG1-42
User Volt 1
25 [%] 25 [%] 25 [%] 25 [%] 25 [%] 25 [%] 25 [%] 25 [%]
FG1-43
User Freq 2
30.00 [Hz]
30.00 [Hz] 30.00 [Hz] 30.00 [Hz] 30.00 [Hz] 30.00 [Hz] 30.00 [Hz] 30.00 [Hz]
FG1-44
User Volt 2 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%] 50 [%]
FG1-45
User Freq 3 45.00 [Hz] 45.00 [Hz] 45.00 [Hz] 45.00 [Hz] 45.00 [Hz] 45.00 [Hz] 45.00 [Hz] 45.00 [Hz]
FG1-46
User Volt 3 75 [%]
75 [%] 75 [%] 75 [%] 75 [%] 75 [%] 75 [%] 75 [%]
FG1-47
User Freq 4 60.00 [Hz]
60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz]
FG1-48
User Volt 4 100[%]
100[%] 100[%] 100[%] 100[%] 100[%] 100[%] 100[%]
FG1-51
Energy Save (None)
(None) (None) (None) (None) (None) (None) (None)
FG1-52
Manual Save% 10 [%]
10 [%] 10 [%] 10 [%] 10 [%] 10 [%] 10 [%] 10 [%]
FG1-57
No Motor Sel [Yes] [Yes] [Yes] [Yes] [Yes] [Yes] [Yes] [Yes]
FG1-58
NoMotorLevel 5 [%] 5 [%] 5 [%] 5 [%] 5 [%] 5 [%] 5 [%] 5 [%]
FG1-59
NoMotorTime 0.2 [sec]
0.2 [sec] 0.2 [sec] 0.2 [sec] 0.2 [sec] 0.2 [sec] 0.2 [sec] 0.2 [sec]
FG1-60
ETH Select [Yes] [Yes] [Yes] [Yes] [Yes] [Yes] [Yes] [Yes]
FG1-61
ETH 1min 150 [%] 150 [%] 150 [%] 150 [%] 150 [%] 150 [%] 150 [%] 150 [%]
FG1-62
ETH Cont 120 [%]
120 [%] 120 [%] 120 [%] 120 [%] 120 [%] 120 [%] 120 [%]
FG1-63
Motor Type (Self-cool)
(Self-cool) (Self-cool) (Self-cool) (Self-cool) (Self-cool) (Self-cool) (Self-cool)
FG1-64
OL Level 105 [%] 105 [%] 105 [%] 105 [%] 105 [%] 105 [%] 105 [%] 105 [%]
FG1-65
OL Time 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec]
FG1-66
OLT Select [Yes]
[Yes] [Yes] [Yes] [Yes] [Yes] [Yes] [Yes]
FG1-67
OLT Level 110[%]
110[%] 110[%] 110[%] 110[%] 110[%] 110[%] 110[%]
FG1-68
OLT Time 30.0 [sec]
30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec]
FG1-69
Trip Select 111 111 111 111 111 111 111 111
FG1-70
Stall Mode Yes Yes Yes Yes No No No Yes
FG1-71
Stall Level 110[%]
110[%] 110[%] 110[%] 110[%] 110[%] 110[%] 110[%]
FG1-72
Acc/Dec Ch F 0 [Hz]
0 [Hz] 0 [Hz] 0 [Hz] 0 [Hz] 0 [Hz] 0 [Hz] 0 [Hz]
FG1-73
Acc/Dec Freq 0 (Max freq) 0 (Max freq) 0 (Max freq) 0 (Max freq) 0 (Max freq) 0 (Max freq) 0 (Max freq) 0 (Max freq)
FG1-74
Time Scale 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec] 0.1 [sec]
FG1-81
Run Delay T 0 [sec]
0 [sec] 0 [sec] 0 [sec] 0 [sec] 0 [sec] 0 [sec] 0 [sec]
FG1-90
UpDnSave (No)
(No) (No) (No) (No) (No) (No) (No)
