Chapter 5 – Parameter List
5-1
CHAPTER 5 - PARAMETER LIST
5.1 [SET] Setup Parameter Group
The parameter codes in gray are hidden until the corresponding feature parameter in bold is activated.
The parameters marked with can be changed during run and with in stop mode only.
CODE
Com.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
SET-00 9100 Application Selection App. Select
none
6-1
Basic
Supp Fan
Exh Fan
Cooling Twr
Circ Pump
Subm. Pump
Vacuum
Const Trq
SET-01 9101 3-phase or Single phase power Input Phase
1-Phase
3-phase
SET-02 9102 Rated Motor HP Motor HP
0.5~700 HP
6-2
SET-03 9103 Rated Motor Current Motor FLA 1.0~999.9A
SET-04 9104 Rated Motor Synchronous RPM Motor RPM
60Hz = 600, 720, 900,
1200, 1800, 3600
50Hz = 500, 600, 750,
1000, 1500, 3000
SET-06 9106 Carrier Frequency Carrier Freq
0.7 ~15.0kHz
40HP = ~10.0kHz
50~100HP = ~ 4.0kHz
125~ 400HP= ~ 3.0kHz
500HP~ = ~ 2.0kHz
SET-07 9107 Input voltage adjustment
VAC575.0V
VAC 440.0
VAC 220.0
77.6~115 [%]
73 to 115.0 [%]
73 to 115.0 [%]
SET-08 9108 Motor Rated Voltage Motor Volt 0 to 600 [V]
SET-09 9109 Run/Stop Method Drive Mode
0
(Keypad)
1
(Remote-1)
2
(Remote-2)
3
(Int. 485)
SET-10 910A
Speed Control Reference Speed Ctrl
0
(Keypad-1)
1
(Keypad-Up/Dwn)
2
(V1)
3
(V1S)
4
(I)
5
(V1+I)
6
(Pulse)
7
(Int. 485)
8
(Ext. PID)
SET-11 910B
Acceleration Time ACC Time 0 to 600.0 [sec]
6-4
SET-12 910C
Deceleration Time DEC Time 0 to 600.0 [sec]
SET-13 910D
V/F Frequency LowLimit Low Limit 0.00 to SET-14
6-4
SET-14 910E
V/F Frequency High Limit High Limit SET-13 to FG1-30
SET-15 910F
Run Prevention Run Prev.
0
(None)
1
(Forward Prev)
2
(Reverse Prev)
SET-16 9110 Stop Mode Stop Mode
0
(Decel)
1
(Dc-brake)
2
(Coast)
3
(Flux-brake)
SET-20 9114 PID Operation Selection PID Mode
0 (No)
6-4
7-1
1 (Yes)
To Next Page
