Chapter 5 – Parameter List
5-2
CODE
Com.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
SET-21 9115 PID Feedback Signal PID F/B
0
(I)
6-4
1
(V1)
2
(Pulse)
SET-22 9116 Feedback Unit Select F/B Unit
0
(PSI)
1
(°F)
2
(°C)
3
(inWC)
4
(inM)
5
(Bar)
6
(mBar)
7
(Pa)
8
(kPa)
9
(CUST)
SET-23 9117 PID Unit Format Unit Format
0
0.01
6-5
1
0.1
SET-25 9119 Feedback Unit Maximum Value F/B Unit Max 0 to 3000.0 [Unit]
SET-26 911A
PID Set Point Value PID SetPoint 0 to SET-25 [Unit]
SET-27 911B
PID Frequency Low Limit PID Limit-L
FG1-32 to SET-28 [Hz]
SET-28 911C
PID Frequency High Limit PID Limit-H SET-27 to FG1-30
SET-29 911D
P Gain for PID Control PID P Gain 0.0 to 999.9 [%]
SET-30 911E
I Gain for PID Control PID I Time 0.0 to 32.0 [sec]
SET-31 911F
PID Output Inverse Out Inverse
0
(No)
1
(Yes)
SET-32 9120 Sleep Mode Frequency Sleep Freq 0.00 to SET-23 [Hz]
6-5
7-2
SET-33 9121 Sleep Mode Delay Time Sleep Delay 0 to 9999 [sec]
SET-34 9122 Sleep Mode Boost Value Sleep Boost 0 to 3000.0 [Unit]
SET-35 9123 Sleep Mode Wake-Up Level WakeUp Level 0.0 to 100.0 [%]
SET-36 9124 PrePID Reference Frequency PrePID Freq 0.00 to FG1-30 [Hz]
6-6
7-4
SET-37 9125 PrePID Stop delay PrePID Dly 0 to 9999.0 [sec]
SET-38 9126 PrePID Exit Level PrePID Exit 0 to 3000.0 [Unit]
SET-40 9128 Pipe Broken Mode Selection PBrokenMode
0 (No)
6-6
7-3
1 (Yes)
SET-41 9129 Pipe Broken Mode Frequency PBrokenFreq 0.00 to FG1-30 [Hz]
SET-42 912A
Pipe Broken Mode Delay Time PBrokenDly 0 to 9999.0 [sec]
SET-43 912B
Pipe Broken Mode Feedback Level PBroken F/B 0 to 3000.0 [Unit]
SET-44 912C
Pipe Broken Mode Output Relay PBrokenRelay
0 None
1 AUX_3
2 AUX_4
SET-50 9132 MMC / Lead-Lag Operation MMC Mode
0 (No)
6-6
1 (Yes)
SET-51 9133 Number of Auxiliary Motors in Use Nbr Aux's 0 to 4
SET-52 9134 Start Frequency of Aux. Motor 1 Start Freq 2
0 to FG1-30 [Hz]
6-7
SET-53 9135 Start Frequency of Aux. Motor 2 Start Freq 2
SET-54 9136 Start Frequency of Aux. Motor 3 Start Freq 3
SET-55 9137 Start Frequency of Aux. Motor 4 Start Freq 4
SET-56 9138 Stop Frequency of Aux. Motor 1 Stop Freq 1
SET-57 9139 Stop Frequency of Aux. Motor 2 Stop Freq 2
SET-58 913A
Stop Frequency of Aux. Motor 3 Stop Freq 3
SET-59 913B
Stop Frequency of Aux. Motor 4 Stop Freq 4
SET-60 913C
Delay Time before Aux Motor Start Aux Start DT 0.0 to 999.9 [sec]
SET-61 913D
Delay Time before Aux Motor Stop Aux Stop DT 0.0 to 999.9 [sec]
SET-62 913E
Accel time when Aux motor stops MMC AccTime 0 to 600.0 [sec]
SET-63 913F
Speed VFD ramps up to when Aux stops MMC AccFreq 0.00 to FG1-30 [Hz]
SET-64 9140 Decel time when Aux motor starts MMC DecTime 0 to 600.0 [sec]
6-7
