Chapter 9 - Options
9.6 DBU Frame 1 dimensions
LED indication description table
LED Description
OHT
(GREEN)
W
hen DB unit heat sink temperature exceeds the internal setting, the Unit trips on Overheat and
OHT LED will be ON.
POWER
(RED)
POWER LED is ON while VFD is powered.
RUN
(GREEN)
RUN LED flashes when DBU sends regenerated energy to resistor.
