Chapter 5 – Parameter List
5-13
5.9 [I/O] Inputs/Outputs parameter group
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
I/O-00 9500 Jump to desired code # Jump Code
1 to 98
6-23
I/O-01 9501 V1 Input Noise Filtering Time V1 Filter 0 to 9999 [msec]
I/O-02 9502 V1 Input Minimum Value V1 Volt x1 0.00 to I/O-04[V]
I/O-03 9503
Frequency at V1 Input Minimum
Value
V1 Freq y1 0.00 to FG1-30 [Hz]
I/O-04 9504 V1 Input Maximum Value V1 Volt x2 I/O-02 to 12.00[V]
I/O-05 9505
Frequency at V1 Input Maximum
Value
V1 Freq y2 0.00 to FG1-30 [Hz]
I/O-06 9506
Noise Filtering Time for I Signal
Input
I Filter 0 to 9999 [msec]
I/O-07 9507 I Input Minimum Value I Curr x1 0.00 to I/O-09 [mA]
I/O-08 9508
Frequency at I Input Minimum
Value
I Freq y1 0.00 to FG1-30 [Hz]
I/O-09 9509 I Input Maximum Value I Curr x2 I/O-07 to 20.00 [mA]
I/O-10 950A
Frequency at I Input Maximum
Value
I Freq y2 0.00 to FG1-30
I/O-11 950B Pulse input type P Pulse Set
0 (A+B)
6-24
1 (A)
I/O-12 950C Pulse input filter time P Filter 0 to 9999 [msec]
I/O-13 950D
Pulse input Minimum Value
(Frequency)
P Pulse x1 0.0 to 10.0 [kHz]
I/O-14 950E
Frequency at Pulse input Minimum
Value
P Freq y1 0.00 to FG1-30 [Hz]
I/O-15 950F
Pulse input Maximum Value
(Frequency)
P Pulse x2 0.0 to 100.0 [kHz]
I/O-16 9510
Frequency at Pulse input Maximum
Value
P Freq y2 0.00 to FG1-30 [Hz]
I/O-17 9511
Criteria for Analog Input Signal
Loss
Wire Broken
0 (None)
1 (half of x1)
2 (below x1)
I/O-18 9512
Operating selection at Loss of Freq.
Reference
Lost Command
0 (Hold)
1 (Coast)
2 (Decel)
3 (Protection)
I/O-19 9513
Waiting Time after Loss of Freq.
Reference
Time Out 0.1 to 120.0 [sec]
I/O-20 9514
Programmable Digital Input
Terminal 'M1' Define
M1 Define
0 (Speed-L)
1 (Speed-M)
2 (Speed-H)
3 (XCEL-L)
4 (XCEL-M)
5 (XCEL-H)
6 (Dc-brake)
7 (2nd Func)
8 (Exchange)
9 (- Reserved -)
10
( Up)
11
(Down)
