5.8 [FG2] Parameter Group Default Settings
CODE
LCD Keypad
Display
Basic Supply
Fan
Exhaust
Fan
Cooling
Tower
Circul.
Pump
Subm.
Pump
Vacuum
Pump
Const.
Torq.
FG2-00
Jump Code 22 22 22 22 22 22 22 22
FG2-06
Erase Trips
No No No No No No No No
FG2-10
Dwell Time 0 [sec] 0 [sec] 0 [sec] 0 [sec] 0 [sec] 0 [sec] 0 [sec] 0 [sec]
FG2-11
Dwell Freq 5.00 [Hz] 5.00 [Hz] 5.00 [Hz] 5.00 [Hz] 40.00 [Hz]
45.00 [Hz] 5.00 [Hz] 5.00 [Hz]
FG2-12
Jump Freq
No No No No No No No No
FG2-13
Jump Low 1 10.00 [Hz]
10.00 [Hz] 10.00 [Hz] 10.00 [Hz] 10.00 [Hz] 10.00 [Hz] 10.00 [Hz] 10.00 [Hz]
FG2-14
Jump High 1 15.00 [Hz]
15.00 [Hz] 15.00 [Hz] 15.00 [Hz] 15.00 [Hz] 15.00 [Hz] 15.00 [Hz] 15.00 [Hz]
FG2-15
Jump Low 2 20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz] 20.00 [Hz]
FG2-16
Jump High 2 25.00 [Hz] 25.00 [Hz] 25.00 [Hz] 25.00 [Hz] 25.00 [Hz] 25.00 [Hz] 25.00 [Hz] 25.00 [Hz]
FG2-17
Jump Low 3 30.00 [Hz]
30.00 [Hz] 30.00 [Hz] 30.00 [Hz] 30.00 [Hz] 30.00 [Hz] 30.00 [Hz] 30.00 [Hz]
FG2-18
Jump High 3 35.00 [Hz]
35.00 [Hz] 35.00 [Hz] 35.00 [Hz] 35.00 [Hz] 35.00 [Hz] 35.00 [Hz] 35.00 [Hz]
FG2-19
Power On Run 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 0 (No)
FG2-20
PwrUpRun Dly
10 [sec] 10 [sec] 10 [sec] 10 [sec] 10 [sec] 10 [sec] 10 [sec] 10 [sec]
FG2-21
RST Restart 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 0 (No)
FG2-22
IPF Mode 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes)
FG2-24
Retry Mode 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 1 (Yes) 0 (No)
FG2-25
Retry Number 3 3 3 3 3 3 3 0
FG2-26
Retry Delay 120 [sec] 120 [sec] 120 [sec] 120 [sec] 120 [sec] 120 [sec] 120 [sec] 120 [sec]
FG2-27
FlySt Level 70 [%] 70 [%] 70 [%] 70 [%] 70 [%] 70 [%] 70 [%] 70 [%]
FG2-30
FlySt Mode
Yes Yes Yes Yes No No Yes Yes
FG2-42
Rated Slip
50 [RPM] 50 [RPM] 50 [RPM] 50 [RPM] 50 [RPM] 150 [RPM] 150 [RPM] 50 [RPM]
FG2-44
Noload Curr
By VFD HP
By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP
FG2-46
InertiaRate 10 10 10 10 10 10 10 10
FG2-47
RPM Scale 100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%]
FG2-49
PWM Mode (Normal 1)
(Normal 1) (Normal 1) (Normal 1) (Normal 1) (Normal 1) (Normal 1) (Normal 1)
FG2-50
Safety Time 100.0 sec 100.0 sec 100.0 sec 100.0 sec 100.0 sec 100.0 sec
100.0 sec 100.0 sec
FG2-51
SafetyGain 21 21 21 21 21 21 21 21
FG2-60
Control Mode 0 (V/F) 0 (V/F) 0 (V/F) 0 (V/F) 0 (V/F) 0 (V/F) 0 (V/F) 0 (V/F)
FG2-61
Auto Tuning
No No No No No No No No
FG2-62
%Rs
By VFD HP
By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP
FG2-63
%Lsigma
By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP By VFD HP
FG2-67
Torque Boost 0 (Manual) 0 (Manual) 0 (Manual) 0 (Manual) 0 (Manual) 0 (Manual) 0 (Manual) 0 (Manual)
FG2-68
Fwd Boost
(150-700HP)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
FG2-69
Rev Boost
(150-700HP)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
2.0%
(1.0%)
FG2-80
PowerOn Disp 0 0 0 0 0 0 0 0
FG2-81
User Disp Voltage Voltage Voltage Voltage Voltage Voltage Voltage Voltage
FG2-87
PowerSet 100 % 100 % 100 % 100 % 100 % 100 % 100 % 100 %
FG2-90
Para. Disp 0 (Default)
0 (Default) 0 (Default) 0 (Default) 0 (Default) 0 (Default) 0 (Default) 0 (Default)
FG2-91
Para. Read
No No No No No No No No
FG2-92
Para. Write
No No No No No No No No
FG2-93
Para. Init
No
No No No No No No No
FG2-94
Para. Lock 0
0 0 0 0 0 0 0
FG2-95
Para. Save
No
No No No No No No No
