Chapter 5 – Parameter List
5-22
5.13 [EXT] Extension parameter group
CODE
Com.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
EXT-00 9700 Jump Code Jump Code 1 to 45
6-37
EXT-01 9701 Type of SUB Board Sub B, D or E Sub-B to E Display
EXT-40 9728 Current Output Terminal 1(CO1)
Selection
AM1 Mode 0
(Frequency)
1
(Current)
2
(Voltage)
3
(DC link Vtg)
4
(Ext PID Out)
EXT-41 9729 Adjust Gain of Current Output Terminal
1(CO1)
AM1 Adjust 10 to 200 [%]
EXT-42 972A Adjust Offset of Current Output Terminal
1(CO1)
AM1 Offset 0 to 100 [%]
EXT-43 972B Current Output Terminal 2(CO2)
Selection
AM2 Mode
Same as EXT-40
EXT-44 972C Adjust Gain of Current Output Terminal
2(CO2)
AM2 Adjust 10 to 200 [%]
EXT-45 972D
Adjust Offset of Current Output Terminal
2(CO2)
AM2 Offset 0 to 100 [%]
5.14 [EXT] Parameter Group Default Settings
CODE
Display
Fan
Fan
Tower
Pump
Pump
Pump
Torq.
EXT-00
Jump Code
EXT-40
AM1 Mode
Frequency Frequency Frequency Frequency Frequency Frequency Frequency Frequency
EXT-41
AM1 Adjust
100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%]
EXT-42
AM1 Offset
0 [%] 0 [%] 0 [%] 0 [%] 0 [%] 0 [%] 0 [%] 0 [%]
EXT-43
AM2 Mode
EXT-44
AM2 Adjust
100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%] 100 [%]
EXT-45
AM2 Offest
0 [%] 0 [%] 0 [%] 0 [%] 0 [%] 0 [%] 0 [%] 0 [%]
5.15 [COM] Communication parameter group
CODE
Addr
Description
Display
Setting Range
Adj.
Page
COM-00 9800 Jump Code Jump Code 1 to 67
6-38
COM-01 9801 Type of SUB Board Opt B/D 0
(RS485)
Display
1
(DeviceNet)
2
(ProfiBus)
3
(BACnet)
4
(LonWorks)
COM-02 9802 Option Control Mode Opt Mode 0
None
1
Command
2
Freq
3
Cmd + Freq
COM-03 9803 Option Version Opt Version Ver X.X
Display
COM-10 980A MAC ID MAC ID 0~63
COM-11 980B Baud Rate Baud Rate 0
125kbps
1
250kbps
2
500kbps
To Next Page
