6.7 Extension Group [EXT]
?)**+B'1 
EXT-00 allows
jumping to any
parameter in EXT group without scrolling to it.
Press [ENTER] key and put a desired parameter
code by using [SHIFT] and [UP]/[DOWN] keys.
When [ENTER] key is pressed again, the desired
parameter will be on the display.
?)*+'8;"  
EXT-01 shows what
type of sub-board is
installed.
?)/*A/7+1!1%!-/)*%
' ' 6!>> 
CO1 and CO2 are analog 4-20mA outputs and they
have five selections: Frequency, Current, Voltage,
kW and External PID Out. EXT-41, 42 and EXT-
44, 45 are parameters for analog outputs scaling
factors and offset.
[Frequency]
CO1 or CO2 output provides 4-20mA signal
corresponding to VFD speed output from 0Hz to
Max. frequency.
[Current]
CO1 or CO2 output provides 4-20mA signal
corresponding to VFD output current from 0A to
VFD current rating.
[Voltage]
CO1 or CO2 output provides 4-20mA signal
corresponding to VFD output voltage from 0V to
Maximum Voltage.
[kW]
CO1 or CO2 output provides 4-20mA signal
corresponding to VFD output kW from 0kW to
Maximum VFD kW output rating.
[Ext.PID Out]
CO1 or CO2 output provides 4-20mA signal
corresponding to VFD External PID output from 0
to 100%.
EXT  Jump Code
00 1
EXT  Sub B/D
01 Sub-E
EXT AM1 Mode
40 Frequency
EXT AM1 Adjust
41 100.0 %
EXT AM1 Offset
42 0.0 %
EXT AM2 Mode
43 Frequency
EXT AM2 Adjust
44 100.0 %
EXT AM2 Offset
45 0.0 %
