CERUS CI-007-P2 - Page 103

Chapter 6 - Parameter Description
6-36
APP  ExtPID Scale
90 100.0 %
%)5*+: "!$' ' 
APP-90 sets the
external PID output
scaling factor.
The default is 100% and it is optimal for most of
the applications.
%)5+: "!$
!
)!
APP-91 sets the
external PID second P-
Gain activated by digital input set to 2
nd
Function.
%)5+: "!$)!
APP-92 sets the
external PID P-Gain
scaling factor.
The default is 100% and it is optimal for most of
the applications.
%)5.+: "!$89!
APP-93 sets the
external PID Feedback
Gain value.
%)57+: "!$' ' $!&"
APP-95 allows
inverting the external
PID output when it is set to Yes.
%)53+: "!$!
APP-95 allows
inverting the external
PID output when it is set to Yes.
APP  Ext P2 Gain
91 100.0 %
APP  Ext P Scale
92 100.0 %
APP  ExtPID FGain
93 0.0 %
APP  ExtPIDOutInv
95 No
APP  ExtPIDLoopT
97 100 ms
