Chapter 11 – Appendix-A UL Marking
vi
CHAPTER 11 - APPENDIX “A”- UL MARKING
11.1 Short Circuit Interrupting Rating
“Suitable for use on a circuit capable of delivering not more than Table1
RMS Symmetrical
Amperes, 240V for 240V, 480V for 480V, 600V for 600V rated VFDs
Volts Maximum,”
Table 1. RMS Symmetrical Amperes for P Series VFDs.
Model Rating
CI-007-P/2, CI-007-P/4, CI-007-P/6, CI-010-P/2, CI-010-P/4, CI-010-P/6,
CI-015-P/2, CI-015-P/4, CI-015-P/6, CI-020-P/2, CI-020-P/4, CI-020-P/6,
CI-025-P/2, CI-025-P/4, CI-025-P/6, CI-030-P/2, CI-030-P/4, CI-030-P/6,
CI-040-P/2, CI-040-P/4, CI-040-P/6, CI-050-P/4, CI-050-P/6,
CI-060-P/4, CI-060-P/6, CI-075-P/4, CI-075-P/6, CI-100-P/4, CI-100-P/6,
CI-125-P/4, CI-125-P/6, CI-150-P/4, CI-150-P/6, CI-200-P/4, CI-250-P/4,
CI-350-P/4, CI-400-P/4, CI-500-P/4, CI-600-P/4, CI-700-P/4,
100,000A
11.2 Branch protection Fuses or Circuit Breaker Sizing
Use Class H or K5 UL Listed Input Fuse and UL Listed Breaker Only. See the table below for the
Voltage and Current rating of the fuses and the breakers.
Input
Voltage
Motor
[HP]
VFD
External Fuse Breaker Internal Fuse
Current
[A]
Voltage
[V]
Current
[A]
Voltage
[V]
Current
[A]
Voltage
[V]
Manufacturer Model Number
200V
Class
7.5 CI-007-P/2 40 500 50 230
10 CI-010-P/2 60 500 60 230
15 CI-015-P/2 80 500 100 230
20 CI-020-P/2 100 500 100 230
25 CI-025-P/2 125 500 225 230
30 CI-030-P/2 150 500 225 230
40 CI-040-P/2 200 500 225 230
400V
Class
7.5 CI-007-P/4 20 500 30 460
10 CI-010-P/4 30 500 30 460
15 Ci-015-P/4 40 500 50 460
20 CI-020-P/4 60 500 60 460
25 CI-025-P/4 70 500 75 460
30 CI-030-P/4 80 500 100 460
40 CI-040-P/4 100 500 125 460
50 CI-050-P/4 125 500 125 460 160 660 Hinode 660GH-160SUL
60 CI-060-P/4 150 500 150 460 160 660 Hinode 660GH-160SUL
75 CI-075-P/4 175 500 175 460 200 660 Hinode 660GH-200SUL
100 CI-100-P/4 250 500 225 460 250 660 Hinode 660GH-250SUL
125 CI-125-P/4 300 500 300 460 315 660 Hinode 660GH-315SUL
150 CI-150-P/4 350 700
400 460
200×2P 660 Hinode 660GH-200SUL×2P
200 CI-200-P/4 400 700
500 460
250×2P 660 Hinode 660GH-250SUL×2P
250 CI-250-P/4 450 700
600 460
315×2P 660 Hinode 660GH-315SUL×2P
350 CI-350-P/4 700 700 800 460 250×3P 660 Hinode 660GH-250SUL×3P
400 CI-400-P/4 800 700
1000 460
315×3P 660 Hinode 660GH-315SUL×3P
500 CI-500-P/4 900 700
1000 460
800 690 Ferraz 6.9URD32TTF0800
600 CI-600-P/4 1000 700
1200 460
900 690 Ferraz 6.9URD32TTF0900
700 CI-700-P/4 1200 700
1200 460
1000 690 Ferraz 6.9URD32TTF1000
