Chapter 5 – Parameter List
5-17
5.10 [I/O] Parameter Group Default Settings
CODE
LCD Keypad
Display
Basic
Supply
Fan
Exhaust
Fan
Cooling
Tower
Circul.
Pump
Subm.
Pump
Vacuum
Pump
Const.
Torq.
I/O-00
Jump Code
28 28 28 28 28 28 28 28
I/O-01
V1 Filter
200 [ms]
200 [ms]
200 [ms]
200 [ms]
200 [ms]
200 [ms]
200 [ms]
200 [ms]
I/O-02
V1 Volt x1
0.00 [V]
0.00 [V]
0.00 [V]
0.00 [V]
0.00 [V]
0.00 [V]
0.00 [V]
0.00 [V]
I/O-03
V1 Freq y1
0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz]
I/O-04
V1 Volt x2
10.00 [V] 10.00 [V] 10.00 [V] 10.00 [V] 10.00 [V] 10.00 [V] 10.00 [V] 10.00 [V]
I/O-05
V1 Freq y2
60.00 [Hz]
60.00 [Hz]
60.00 [H
z]
60.00 [Hz]
60.00 [Hz]
60.00 [Hz]
60.00 [Hz]
60.00 [Hz]
I/O-06
I Filter
100 [ms] 100 [ms] 100 [ms] 100 [ms] 100 [ms] 100 [ms] 100 [ms] 100 [ms]
I/O-07
I Curr x1
4.00 [mA] 4.00 [mA] 4.00 [mA] 4.00 [mA] 4.00 [mA] 4.00 [mA] 4.00 [mA] 4.00 [mA]
I/O-08
I Freq y1
0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz]
I/O-09
I Curr x2
20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA] 20.00 [mA]
I/O-10
I Freq y2
60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz]
I/O-11
P Pulse Set
1 (A)
1 (A)
1 (A)
1 (A)
1 (A)
1 (A)
1 (A)
1 (A)
I/O-12
P Filter
10 [ms] 10 [ms] 10 [ms] 10 [ms] 10 [ms] 10 [ms] 10 [ms] 10 [ms]
I/O-13
P Pulse x1
0.0 [kHz] 0.0 [kHz] 0.0 [kHz] 0.0 [kHz] 0.0 [kHz] 0.0 [kHz] 0.0 [kHz] 0.0 [kHz]
I/O-14
P Freq y1
0.00 [Hz]
0.00 [Hz]
0.00 [Hz]
0.00 [Hz]
0.00 [Hz]
0.00 [Hz]
0.00 [Hz]
0.00 [Hz]
I/O-15
P Pulse x2
10.0 [kHz] 10.0 [kHz] 10.0 [kHz] 10.0 [kHz] 10.0 [kHz] 10.0 [kHz] 10.0 [kHz] 10.0 [kHz]
I/O-16
P Freq y2
60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz] 60.00 [Hz]
I/O-17
Wire Broken
0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None)
I/O-18
Lost Command
1 (Coast)
1 (Coast)
1 (Coast)
1 (Coast)
1 (Coast)
1 (
Coast)
1 (Coast)
1 (Coast)
I/O-19
Time Out
1.0 [sec] 1.0 [sec] 1.0 [sec] 1.0 [sec] 1.0 [sec] 1.0 [sec] 1.0 [sec] 1.0 [sec]
I/O-20
M1 Define
0(Speed
-
L)
0(Speed
-
L)
0(Speed
-
L)
0(Speed
-
L)
0(Speed
-
L)
0(Speed
-
L)
0(Speed
-
L)
0(Speed
-
L)
I/O-21
M2 Define
1 (Speed-M) 1 (Speed-M) 1 (Speed-M) 1 (Speed-M) 1 (Speed-M) 1 (Speed-M) 1 (Speed-M) 1 (Speed-M)
I/O-22
M3 Define
2 (Speed-H) 2 (Speed-H) 2 (Speed-H) 2 (Speed-H) 2 (Speed-H) 2 (Speed-H) 2 (Speed-H) 2 (Speed-H)
I/O-23
M4 Define
27 (RST) 27 (RST) 27 (RST) 27 (RST) 27 (RST) 27 (RST) 27 (RST) 27 (RST)
I/O-24
M5 Define
28 ( BX )
28 ( BX )
28 ( BX )
28 ( BX )
28 ( BX )
28 ( BX )
28 ( BX )
28 ( BX )
I/O-25
M6 Define
29 (JOG) 29 (JOG) 29 (JOG) 29 (JOG) 29 (JOG) 29 (JOG) 29 (JOG) 29 (JOG)
I/O-26
M7 Define
30 (FX) 30 (FX) 30 (FX) 30 (FX) 30 (FX) 30 (FX) 30 (FX) 30 (FX)
I/O-27
M8 Define
31 (RX)
31 (RX)
31 (RX)
31 (RX)
31 (RX)
31 (RX)
31 (RX)
31 (RX)
I/O-29
DI Filter
15 [ms] 15 [ms] 15 [ms] 15 [ms] 15 [ms] 15 [ms] 15 [ms] 15 [ms]
I/O-30
BX Self Reset
Yes Yes Yes Yes Yes Yes Yes No
I/O-50
Acc Time-1
20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec]
I/O-51
Dec Time-1
20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec]
I/O-52
Acc Time-2
30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec]
I/O-53
Dec Time-2
30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec]
I/O-54
Acc Time-3
40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec]
I/O-55
Dec Time-3
40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec]
I/O-56
Acc Time-4
50.0 [sec] 50.0 [sec] 50.0 [sec] 50.0 [sec] 50.0 [sec] 50.0 [sec] 50.0 [sec] 50.0 [sec]
I/O-57
Dec Time-4
50.0 [sec]
50.0 [sec]
50.0 [sec]
50.0 [sec]
50.0 [sec]
50.0 [sec]
50.0 [sec]
50.0 [sec]
I/O-58
Acc Time-5
40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec]
I/O-59
Dec Time-5
40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec] 40.0 [sec]
I/O-60
Acc Time-6
30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec]
I/O-61
Dec Time-6
30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec] 30.0 [sec]
I/O-62
Acc Time-7
20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec] 20.0 [sec]
I/O-63
Dec Time-7
20.0 [sec]
20.0 [sec]
20.0 [sec]
20.0 [sec]
20.0 [sec]
20.0 [sec]
20.0 [sec]
20.0 [sec]
I/O-68
Dmpr LubeSel
0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None) 0 (None)
I/O-69
DmpLubeTMR
30 [sec] 30 [sec] 30 [sec] 30 [sec] 30 [sec] 30 [sec] 30 [sec] 30 [sec]
I/O-70
S0 Mode
0 (Frequency)
0 (Frequency) 0 (Frequency) 0 (Frequency) 0 (Frequency) 0 (Frequency) 0 (Frequency) 0 (Frequency)
I/O-71
S0 Adjust
100 [%]
100 [%]
100 [%]
100 [%]
100 [%]
100 [%]
100 [%]
100 [%]
