Chapter 5 – Parameter List
5-16
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
I/O-77 954D
Programmable Digital Auxiliary
Relay2 Define (A2-C2)
Aux Relay2
Same as I/O-76
I/O-78 954E
Programmable Digital Auxiliary
Relay3 Define (A3-C3)
Aux Relay3
Same as I/O-76
I/O-79 954F
Programmable Digital Auxiliary
Relay4 Define (A4-C4)
Aux Relay4
Same as I/O-76
I/O-80 9550 Fault Relay Setting (3A, 3B, 3C) FltRelayMode 000 to 111 [bit] 6-31
I/O-81 9551 Output Relays Status Out Status
Display
6-31
I/O-82 9552 Fault Relay On Delay RelayOnDly 0 to 9999sec
I/O-83 9553 Fault Relay Off Delay RelayOffDly 0 to 9999sec
I/O-84 9554
Fan Control Mode Selection (Only
for 50HP VFD and above)
Fan Control
0 Power On
1 Run
2 Temperature
I/O-85 9555 Fan Start Temp (50HP and above) Fan Temp 0 to 70 [°C]
I/O-90 955A Inverter Communication ID# Inv No. 1 to 250
I/O-91 955B Baud Rate Selection Baud Rate
0 (1200 bps)
1 (2400 bps)
2 (4800 bps)
3 (9600 bps)
4 (19200 bps)
5 (38400 bps)
I/O-92 955C
Operating Method at Loss of
Communication
COM Lost Cmd
0 (Hold)
1 (Coast)
2 (Decel)
I/O-93 955D Timer for Loss off Communication COM Time Out
0.1-120.0 sec.
I/O-94 955E Comm. Response Delay Time Delay Time
2-1000 sec.
I/O-95 955F Digital Inputs N.O./N.C. Selection
In No/Nc Set
00000000000 <…..M2,M1
I/0-97 9561 Motor Overheat Trip Selection OH Trip Sel
000 to 111 [bit]
6-32
I/0-98 9562 Motor overheat trip temperature MotTripTemp.
0 to 255 [°C]
