Chapter 5 – Parameter List
5-15
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
I/O-55 9537 Deceleration Time 3 Dec Time-3
I/O-56 9538 Acceleration Time 4 Acc Time-4
I/O-57 9539 Deceleration Time 4 Dec Time-4
I/O-58 953A Acceleration Time 5 Acc Time-5
I/O-59 953B Deceleration Time 5 Dec Time-5
I/O-60 953C Acceleration Time 6 Acc Time-6
I/O-61 953D Deceleration Time 6 Dec Time-6
I/O-62 953E Acceleration Time 7 Acc Time-7
I/O-63 953F Deceleration Time 7 Dec Time-7
I/O-68 9544 Damper or Lubrication Mode Dmpr LubeSel
0 (None)
6-27
1 (Damper)
2 (Lubrication)
I/O-69 9545 Damper/Lubrication Relay Timer Dmpr/LubeTmr 0 to 6000 [sec]
I/O-70 9546 S0 Output Selection S0 Mode
0 (Frequency)
1 (Current)
2 (Voltage)
3 (kW)
4 (Ext PID Out)
I/O-71 9547 S0 Output Scale S0 Adjust 10 to 200 [%]
I/O-72 9548 S1 Output Selection S1 Mode Same as I/O-70
I/O-73 9549 S1 Output Scale S1 Adjust 10 to 200 [%]
I/O-74 954A Frequency Detection Level FDT Freq 0.00 to FG1-30 [Hz]
6-28
I/O-75 954B Frequency Detection Bandwidth FDT Band 0.00 to FG1-30 [Hz]
I/O-76 954C
Programmable Digital Auxiliary
Relay1 Define (A1-C1)
Aux Relay1
0 (NONE)
1 (FDT-1)
2 (FDT-2)
3 (FDT-3)
4 (FDT-4)
5 (FDT-5)
6 (OL)
7 (IOL)
8 (Stall)
9 (OV)
10
(LV)
11
(OH)
12
(Lost Command)
13
(RUN)
14
(STOP)
15
(Steady)
16
(INV Line)
17
(COMM Line)
18
(SpeedSearch)
19
(Ready)
20
(MMC)
21
(Local)
22
(Remote)
23
(PIPE BROKEN)
24
(DAMPER)
25
(LUBRICATION)
26
(LEVEL DETECT)
To Next Page
