Chapter 5 – Parameter List
5-14
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
12
(3-Wire)
13
(Ext Trip)
14
(Pre-Heat)
15
(iTerm Clear)
16
(Open-loop)
17
(LOC/REM)
18
(Analog hold)
19
(XCEL stop)
20
(P Gain2)
21
(- Reserved -)
22
(interlock1)
23
(interlock2)
24
(interlock3)
25
(interlock4)
26
(Speed_X)
27
(RST)
28
(BX)
29
(JOG)
30
(FX)
31
(RX)
32
(ANA_CHG)
33
(Ext PID Run)
34
(Up/Dn Clr)
35
(JOG_FX)
36
(JOG_RX)
37
(Damper Sw)
38
(Smoke Purge)
I/O-21 9515
Programmable Digital Input
Terminal 'M2' Define
M2 Define
Same as I/O-20
6-24
I/O-22 9516
Programmable Digital Input
Terminal 'M3' Define
M3 Define
Same as I/O-20
I/O-23 9517
Programmable Digital Input
Terminal 'M4' Define
M4 Define
Same as I/O-20
I/O-24 9518
Programmable Digital Input
Terminal 'M5' Define
M5 Define
Same as I/O-20
I/O-25 9519
Programmable Digital Input
Terminal 'M6' Define
M6 Define
Same as I/O-20
I/O-26 951A
Programmable Digital Input
Terminal 'M7' Define
M7 Define
Same as I/O-20
I/O-27 951B
Programmable Digital Input
Terminal 'M8' Define
M8 Define
Same as I/O-20
I/O-28 951C Digital Inputs Status In Status 00000000000 (bit) Display
6-26
I/O-29 951D Digital Input Filter Time DI Filter 2-1000 ms
I/O-30 951E BX Self Reset BX Self Reset
0 (No)
1 (Yes)
I/O-50 9532 Acceleration Time 1 (for St1 speed) Acc Time-1
0.0 to 600.0 [sec]
I/O-51 9533 Deceleration Time 1 (for St1 speed) Dec Time-1
I/O-52 9534 Acceleration Time 2 Acc Time-2
I/O-53 9535 Deceleration Time 2 Dec Time-2
I/O-54 9536 Acceleration Time 3 Acc Time-3
To Next Page
