Chapter 5 – Parameter List
5-20
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Run
Adj.
Page
APP-68 9644 Auto Change Level AutoEx Level FG-32 to FG1-30 [Hz]
6-35
APP-69 9645 Inter-Lock Selection Interlock
0
(No)

1 (Yes)
APP-78 964E Ext PID Operation Selection Ext PI Mode
0
(No)

1 (Yes)
APP-79 964F Ext PID Reference Signal Selection Ext Ref Sel
0
(I)
1 (V1)
2 (Pulse)
3 (Key-Pad)
APP-80 9650 Ext PID Set Point Ext SetPoint 0.0 to 3000.0 [Unit]

APP-81 9651 Ext PID Feedback Signal Selection Ext Fbk Sel
0
(I)

1 (V1)
2 (Pulse)
APP-82 9652 Ext PID Feedback Unit Select ExtFbk Unit
PSI, °F, °C, inWC,
inM, Bar, mBar, Pa,
kPa, CUST
APP-84 9654 Ext PID Fdbk Unit Max Value ExtFbk UnitH 0.0 to 3000.0 [Unit]
APP-85 9655 P Gain for ExtPID ExtPID PGain 0.0 to 999.9 [%]
APP-86 9656 I Time for ExtPID ExtPID ITime 0.0 to 32.0 [sec]
APP-87 9657 D Time for ExtPID ExtPID DTime 0 to 2000 [msec]
APP-88 9658
High Limit Frequency for ExtPID
Control
ExtPID Lmt H 0.00 to 100.00 [%]

APP-89 9659
Low Limit Frequency for ExtPID
Control
ExtPID Lmt L 0.00 to 30.00 [%]
APP-90 965A ExtPID Output Scale ExtPID Scale 0.0 to 999.9

6-36
APP-91 965B ExtPID P2 Gain Ext P2 Gain 0.0 to 999.9
APP-92 965C ExtPID P Gain Scale Ext P Scale 0.0 to 100.0
APP-93 965D ExtPID F Gain ExtPID FGain 0.0 to 999.9 [%]

APP-95 965F ExtPID Output Inverse ExtPIDOutInv
0 (No)

1 (Yes)
APP-97 9661 ExtPID Loop Time ExtPIDLoopT 50 to 200 [msec]

