Chapter 10 – Modbus-RTU Communication
10-4
Address Parameter Unit Unit R/W Data value
BIT13: REM. R/S (Int. 485, OPT)
BIT14: REM. Freq. (Int. 485, OPT)
0x000F Trip information R
BIT 0 : OCT1
BIT 1 : OV
BIT 2 : EXT-A
BIT 3 : BX
BIT 4 : LV
BIT 5 : RESERVE
BIT 6 : GF(Ground Fault)
BIT 6: OHT (VFD overheat)
BIT 7: ETH (Motor overheat)
BIT 8: OLT (Overload trip)
BIT10: HW-Diag
BIT11: RESERVE
BIT12: OCT2
BIT13: OPT (Option error)
BIT14 : PO (Phase Open)
BIT15: IOLT
0x0010 Input terminal status
R
BIT 0 : M1
BIT 1 : M2
BIT 2 : M3
BIT 3 : M4
BIT 4 : M5
BIT 5 : M6
BIT 6 : M7
BIT 7 : M8
BIT 8 : RESERVED
BIT 9 : RESERVED
BIT 10 : RESERVED
0x0011 Output terminal status R
BIT 0 : AUX1
BIT 1 : AUX2
BIT 2 : AUX3
BIT 3 : AUX4
BIT 4 : RESERVED
BIT 5 : RESERVED
BIT 6 : RESERVED
BIT 7 : 30AC
0x0012 V1 0~10V R
0x0013 V2 0~10V R
0x0014 I 0~20mA R
0x0015 RPM R
0x001A Unit display R
0 : Hz, 1 : Rpm
0x001B Pole number R
0x001C Custom Version R
