CERUS CI-007-P2 - Page 47

Chapter 5 – Parameter List
5-4
CODE
LCD Keypad
Display
Basic
Supply
Fan
Exhaust
Fan
Cooling
Tower
Circul.
Pump
Subm.
Pump
Vacuum
Pump
Const.
Torq.
SET-21 PID F/B I I I I I I I I
SET-22 F/B Unit CUST inWC inWC °F PSI PSI inWC CUST
SET-23 Unit Format 0.1 0.01 0.01 0.1 0.1 0.1 0.1 0.1
SET-25 F/B Unit Max 100.0 1.00 1.00 122.0 100.0 100.0 406.9 100.0
SET-26 PID SetPoint
50.0 [CUST] 0.50 [inWC] 0.50 [inWC] 80.0 [°F] 50.0 [PSI] 50.0 [PSI] 60.0 [inWC] 10.0 [CUST]
SET-27 PID Limit-L 20.00Hz 20.00Hz 20.00Hz 20.00Hz 30.00Hz 30.00Hz 30.00Hz 10.00Hz
SET-28 PID Limit-H 60.00Hz 60.00Hz 60.00Hz 60.00Hz 60.00Hz 60.00Hz 60.00Hz 60.00Hz
SET-29 PID P Gain 1.0 [%] 1.0 [%] 1.0 [%] 10.0 [%] 10.0 [%] 50.0 [%] 50.0 [%] 1.0 [%]
SET-30 PID I Time 1.0 [sec] 1.0 [sec] 1.0 [sec] 1.0 [sec] 1.0 [sec] 0.5 [sec] 0.5 [sec] 1.0 [sec]
SET-31 Out Inverse No No Yes Yes No No No No
SET-32 Sleep Freq 0.00[Hz] 0.00[Hz] 0.00 [Hz] 0.00 [Hz] 35.00 [Hz] 35.00 [Hz] 0.00 [Hz] 0.00 [Hz]
SET-33 Sleep Delay 20 [sec] 20 [sec] 20 [sec] 20 [sec] 20 [sec] 20 [sec] 20 [sec] 20 [sec]
SET-34 Sleep Boost 0.0 CUST 0.00 inWC 0.00 inWC 0.00 °F 2.0 PSI 3.0 PSI 5.0 inWC 0.0 CUST
SET-35 WakeUp Level 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%]
SET-36 PrePID Freq 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 37.00 [Hz] 0.00 [Hz] 0.00 [Hz]
SET-37 PrePID Dly 60 [sec] 60 [sec] 60 [sec] 60 [sec] 60 [sec] 180 [sec] 60 [sec] 60 [sec]
SET-38 PrePID Exit 25.0 CUST 0.25 inWC 0.25 inWC 40.0 °F 25.0 PSI 25.0 PSI 30.0 inWC 5.0 CUST
SET
-
40
PBrokenMode
No
No
No
No
No
Yes
No
No
SET-41 PBrokenFreq 59.00 Hz 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 Hz
SET-42 PBrokenDly 30 [sec] 30 [sec] 30 [sec] 30 [sec] 30 [sec] 30 [sec] 30 [sec] 30 [sec]
SET-43 PBroken F/B 5.0 CUST 0.05 inWC 0.05 inWC 8.0 [°F] 50.0 [PSI] 50.0 [PSI] 6.0 inWC 1.0 CUST
SET-44 PBrokenRelay None None None None None None None None
SET-50 MMC Mode No No No No No No No No
SET-51 Nbr Aux's 1 1 1 1 1 1 1 1
SET-52 Start Freq 2 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz]
SET-53 Start Freq 2 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz]
SET-54 Start Freq 3 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz]
SET-55 Start Freq 4 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz]
SET-56 Stop Freq 1 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz]
SET-57 Stop Freq 2 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz]
SET-58 Stop Freq 3 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz]
SET-59 Stop Freq 4 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz] 40.00 [Hz]
SET-60 Aux Start DT 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec] 5.0 [sec]
SET-61 Aux Stop DT 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec]
SET-62 MMC AccTime 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec] 2.0 [sec]
SET-63 MMC AccFreq 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz]
SET-64 MMC DecTime 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 10.0 [sec] 30.0 [sec] 10.0 [sec]
SET-65 MMC DecFreq 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 0.00 [Hz] 55.00 [Hz] 55.00 [Hz] 0.00 [Hz] 0.00 [Hz]
SET-66 AuxStartDiff 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%]
SET-67 AuxStopDiff 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%] 2.0 [%]
SET
-
74
Level Detect
No
No
No
No
No
Under Lvl
No
No
SET-75 LDT Source Current Current Current Current Current Current Current Current
SET-76 LDT Freq 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 59.00 [Hz] 40.00 [Hz] 59.00 [Hz] 59.00 [Hz]
SET-77 LDT Delay 2 [sec] 2 [sec] 2 [sec] 2 [sec] 2 [sec] 1[sec] 2 [sec] 2 [sec]
SET-78 LDT Level
[SET-3]
x0.7
[SET-3]
x0.7
[SET-3]
x0.7
[SET-3]
x0.7
[SET-3]
x0.7
[SET-3]
x0.7
[SET-3]
x0.7
[SET-3]
x0.7
SET-79 LDT Hyst 0.0 [A] 1.0 [A] 1.0 [A] 1.0 [A] 1.0 [A] 1.0 [A] 1.0 [A] 1.0 [A]
SET-80 LDT Trip No No No No No Yes No No
SET-81 LDT FillTime 60.0 [min] 60.0 [min] 60.0 [min] 60.0 [min] 60.0 [min] 60.0 [min] 60.0 [min] 60.0 [min]
SET-82 LDT Relay None None None None None None None None
SET-90 LocalRemKey
Control
Stop
Cntl&Ref
Stop
Cntl&Ref
Stop
Cntl&Ref
Stop
Cntl&Ref
Stop
Cntl&Ref
Stop
Cntl&Ref
Stop
Cntl&Ref
Stop
