Chapter 9 - Options
9-8
 Conduit Hole Size
mm(inches)
VFD
Conduit hole for control terminal
Size of the Conduit
Conduit hole for power terminal
CI-007-P2/4
24 (0.98) 16 (1/2)
24 (0.98) 16 (1/2)
CI-010-P2/4
24 (0.98) 16 (1/2)
35 (1.37) 27 (1)
CI-015-P2/4
24 (0.98) 16 (1/2)
35 (1.37) 27 (1)
CI-020-P2/4
35 (1.37) 27 (1)
50 (1.96) 41 (3/2)
CI-025-P2/4
35 (1.37) 27 (1)
50 (1.96) 41 (3/2)
CI-030-P2/4
50 (1.96) 41 (3/2)
50 (1.96) 41 (3/2)
CI-040-P2/4
50 (1.96) 41 (3/2)
50 (1.96) 41 (3/2)
CI-050-P2/4
22(0.86) 16(1/2)
51(2.00) 41(3/2)
CI-060-P2/4
22(0.86) 16(1/2)
51(2.00) 41(3/2)
CI-075-P2/4
22(0.86) 16(1/2)
51(2.00) 41(3/2)
CI-100-P2/4
22(0.86) 16(1/2)
76(2.99) 63(5/2)
CI-125-P2/4
22(0.86) 16(1/2)
76(2.99) 63(5/2)
